SM200C — 20 GHz Real-time Spectrum Analyzer

The SM200C is a high-performance spectrum analyzer and monitoring receiver with a 10 Gigabit Ethernet SFP+ port, enabling the SM200C to communicate with a PC over long distances using a fiber optic cable. Designed for remotely-located accurate RF data analysis at the lowest cost possible.


A 10GbE-connected spectrum analyzer unrivaled in value

The SM200C is a high-performance spectrum analyzer and monitoring receiver with a 10 Gigabit Ethernet SFP+ port, enabling the SM200C to communicate with a PC over long distances using a fiber optic cable. Designed for remotely-located accurate RF data analysis at the lowest cost possible, the SM200C features:

  • 160 MHz instantaneous bandwidth I/Q streaming over 10GbE
  • SFP+ port for fast, long-distance communication with a PC using an optic cable
  • Device control and data transfer occurs via SFP+ connection, not USB
  • Tunes from 100 kHz to 20 GHz
  • Sweeps at 1 THz/sec at 30 kHz RBW
  • 110 dB of dynamic range
  • Ultra-low phase noise
  • GPIO port antenna switching

ModeSM200C
Frequency Range100 kHz to 20GHz
Sweep Speed

Speed                            RBW
• 1 THz/sec                    ≥30 kHz
• 160 GHz/sec               10 kHz
• 18 GHz/sec                 1 kHz

Displayed Average
Noise Level (DANL)
REF LEVEL ≤ -20 dBm
Input Frequency Range              dBm/Hz
• 100 kHz to 700 MHz                -156 dBm
• 700 MHz to 2.7 GHz                -160 dBm
• 2.7 GHz to 4.5 GHz                  -158 dBm
• 4.5 GHz to 8.5 GHz                  -153 dBm
• 8.5 GHz to 15 GHz                   -154 dBm
• 15 GHz to 20 GHz                    -151 dBm
I/Q Acquisition Modes

Calibrated Streaming I/Q:

Up to 160MHz of selectable I/Q streaming bandwidth

Timebase Accuracy

• ±5 x 10-10 when locked to GPS
• Holdover of ±5 x 10-9 /day for aging (±2 x 10-8 first day typ)
• Holdover of ±1 x 10-8 for temperature over -40°C to 65°C (typ)

System Noise Figure (typ)• 11 dB over 700 MHz to 2.7 GHz
• 14 dB from 2.5 GHz to 4.5 GHz
• 18 dB from 4.5 GHz to 15 GHz
LinearityIP2                                                          IP3
• 100 kHz to 2 GHz      +64 dBm      • 100 kHz to 4 GHz       +28 dBm
• 2 GHz to 11 GHz       +74 dBm      • 4 GHz to 6 GHz           +23 dBm
• 11 GHz to 13.5 GHz  +76 dBm      • 6 GHz to 14 GHz         +18 dBm
• 13.5 GHz to 20 GHz  +60 dBm      • 14 GHz to 20 GHz       +23 dBm
Amplitude Accuracy
100 kHz to 6 GHz           6 GHz to 20 GHz            RBW filter shape
• ± 2.0 dB                        • ± 3.0 dB                        • Flat-Top windowing
Residual Responses
REF LEVEL ≤ -20 dBm
• 100 kHz to 8.0 MHz          -110 dBm
• 8.0 GHz to 15 GHz            -100 dBm
• 15 GHz to 20 GHz             -90 dBm
SSB Phase Noise at 1 GHz
Center Frequency		Offset Frequency          dBc/Hz
• 10 Hz                              -76
• 100 Hz                            -108
• 1 kHz                              -123
• 10 kHz                            -132
• 100 kHz                          -136
• 1 MHz                            -133
Lo Leakage at RF Input

• 100 kHz to 5 GHz                                  -82 dBm
• 5 GHz to 10 GHz                                   -55 dBm
• 10 GHz to 18 GHz                                 -50 dBm
• 18 GHz to 20 GHz                                 -47 dBm

Spurious Mixer Responses• 100 kHz to 6 GHz                                  -58 dBc
• 6 GHz to 10 GHz                                   -55 dBc
• 10 GHz to 20 GHz                                 -44 dBc
Sub-Octave Preselector Filters20 MHz to 20 GHz
SynchronizationExternal trigger, GPIO, Internal GPS (+/-40ns)
Operating Temperature
Standard (passive cooling) 32°F to 122°F (0°C to +50°C)
Size and Weight • 10.2" x 7.2" x 2.15" (259mm x 183mm x 55mm)  • 7.77 lbs. (3.52 kg)
Power Consumption• 9 to 16 VDC • 33 Watt Maximum
Interface10GbE SFP+ port
System RequirementsWindows or Linux Operating System, x64_86 architecture
